Alpine Custom DIY Play Set Hardware Kit by Swing-N-Slide

$230.00

Delight your little discoverers! This exciting, single-tower Alpine Swing Set by Swing-N-Slide gives you tons of fun and lots of customizable details. In fact, this Playset Hardware Kit comes with four different DIY design brackets, two...

8 activities for up to 6 kids, ages 2-10 years
Plastisol coated chains prevent pinched fingers and will not rust
Includes two swings, a trapeze bar, handholds, wave slide, rope ladder, vinyl canopy
Lumber not included

ages: 2+

technical information

Item Number: WS 5007

Space Requirements: 28'x33'
Packaged Dimensions: 21.5" L x 11" W x 11.5" H
Packaged Weight: 35 lbs.
Weight Assembled: 34.5 lbs.
Swing Positions: 4
Materials: HDPE, EVA, Steel, UV Coated, HDPE Laminate
Safety Certifications: ASTM and CPSIA compliant
Tools Required: Drill 1/8" drill bit 7/16" & 1/2" sockets & wrench Hammer Adjustable wrench Tape Measure Screw driver Phillips Bit Carpenter Square Safety Glasses Pliers Ladder

Lumber Required:
Alpine 601: 5- 2 x 4 x 8 ft. 3- 2 x 4 x 10 ft. 8- 5/4 x 6 x 10 ft. 3- 5/4 x 6 x 12 ft. 8- 4 x 4 x 8 ft. 1- 4 x 4 x 10 ft. 1- 4 x 6 x 12 ft. or 2- 2 x 6 x 12 ft. 1 lb 8 x 1 1/4 inch screws 1 lb 8 x 2 inch screws 1 lb 8 x 2 1/2 inch screws 1 lb 8 x 3 inch screws
Alpine 602: 5- 2 x 4 x 8 ft. 3- 2 x 4 x 10 ft. 8- 5/4 x 6 x 10 ft. 3- 5/4 x 6 x 12 ft. 8- 4 x 4 x 8 ft. 1- 4 x 4 x 10 ft. 1- 4 x 6 x 12 ft. or 2- 2 x 6 x 12 ft. 1 lb 8 x 1 1/4 inch screws 1 lb 8 x 2 inch screws 1 lb 8 x 2 1/2 inch screws 1 lb 8 x 3 inch screws
Alpine 613: 5- 2 x 4 x 8 ft. 3- 2 x 4 x 10 ft. 6- 5/4 x 6 x 10 ft. 4- 5/4 x 6 x 12 ft. 4- 4 x 4 x 8 ft. 5- 4 x 4 x 10 ft. 1- 4 x 6 x 12 ft. or 2- 2 x 6 x 12 ft. 1 lb 8 x 1 1/4 inch screws 1 lb 8 x 2 inch screws 1 lb 8 x 2 1/2 inch screws 1 lb 8 x 3 inch screws
